12.1″High definition LED monitor , Linux system2 Activated transducer connectorsRaw data storage for offline report and parameter adjustment, 500GB large storage capacity Image Mode: B, B Steer, 2B/4B, M, B/M, CDFI, PDI, CM, PW, AMM, CW, TDI (TVI, TVD, TVM, TEI), Panoramic, Color Panoramic, TrapezoidalExtended Imaging (EFov), TSI, THI, Speckle Reduction Imaging (SRI) Spatial Composite Imaging (SCI), Frequency Composite Imaging (FCI)B/C/D Chromatic ImagingMUC-320 Hand-carried Color doppler Ultrasound Diagnostic System
Main Features
1. 2D, CFM, M, PW, CW, CMM, DPDI, AMM, 3D/4D, ZPage, ZLive, TDI, Elastic Imaging, Panoramic Imaging
2. THI, SRI, SCI, TSI, FCI, EFov, HR flow, B-steer
3. Standard Auto IMT measurement
4. Support local and global amplification
5. Support PW auto trace and auto calculation
6. Preposed USB ports, supporting multi-data transmission
7. Dual Live and Multi-synchronization technologies
8. Biopsy function
Technical Advantages
uSeed Platform
MUC-320 facilitates accurate diagnosis based on uSeed metadata beamforming imaging technology platform. This brand. new platform
is developed
byCPU + GPU heterogeneous computing technology. The images in uSeed platform are saved as metadata for postprocessing.
Pulse Inverse Harmonic Imaging PIHI
PIHI reduces the distortion generated by the fundamental wave, and greatly improve the signal-to-noise ratio.
Speckle Reduction Imaging
SRI technology significantly reduces the unwanted speckle, provides enhanced tissue boundary and tissue echo for confident clinical diagnosis.
Spatial Compound Imaging
SCI provides better contrast resolution, reduces the speckle noise and smoothes the imaging of homogeneous tissue.
